MOOG 0062-191C 伺服放大器 PDF資料
1.產 品 資 料 介 紹：
MOOG 0062-191C 伺服放大器說明
一、總體概述
MOOG 0062-191C 是一款高性能伺服放大器，用于驅動液壓或電動伺服閥，屬于 MOOG 0062 系列。
該伺服放大器主要用于工業自動化、機床控制、測試平臺和航空系統中，提供精確的電信號控制，實現執行器的高精度動作。
它能夠?qū)⒖刂破鬏敵龅牡凸β手噶钚盘柗糯鬄榭沈?qū)動伺服閥的電流或電壓，實現精確控制。
二、主要特性
類型：伺服放大器，用于驅動液壓或電動伺服閥
輸入信號：接受 ±10V 或 ±12V 模擬信號（依具體系統而定）
輸出：為伺服閥提供驅動電流或電壓，實現流量或壓力控制
響應速度：高動態響應，適合高速控制系統
精度與穩定性：保證伺服閥動作精確和重復性高
安裝形式：可插入機架或獨立安裝
冷卻方式：風冷或自然散熱，依型號設計
三、功能特點
高精度放大
能夠?qū)⒌凸β士刂菩盘柧_放大為伺服閥可用的驅動信號，保證執行器動作精準。快速響應
優化的電路設計，實現高速信號放大和閥門驅動響應，滿足動態控制要求。可靠性高
高質量電子元件和穩健設計，保證在工業環境下長期穩定運行。兼容性強
可與 MOOG 系列伺服閥配合使用，包括比例閥和伺服閥，實現整體液壓系統控制。調試方便
支持外部參數調整和電氣接口調試，便于系統集成和性能優化。
MOOG 0062-191C 伺服放大器 英文介紹
MOOG 0062-191C Servo Amplifier Description
1、 Overall Overview
MOOG 0062-191C is a high-performance servo amplifier used to drive hydraulic or electric servo valves, belonging to the MOOG 0062 series.
This servo amplifier is mainly used in industrial automation, machine tool control, testing platforms, and aviation systems to provide precise electrical signal control and achieve high-precision action of actuators.
It can amplify the low-power command signal output by the controller into a current or voltage that can drive the servo valve, achieving precise control.
2、 Main characteristics
Type: Servo amplifier, used to drive hydraulic or electric servo valves
Input signal: accepts ± 10V or ± 12V analog signals (depending on the specific system)
Output: Provide driving current or voltage for servo valves to achieve flow or pressure control
Response speed: High dynamic response, suitable for high-speed control systems
Accuracy and stability: Ensure precise and high repeatability of servo valve action
Installation form: Can be inserted into the rack or installed independently
Cooling method: air cooling or natural heat dissipation, designed according to the model
3、 Functional Features
High precision amplification
Capable of accurately amplifying low-power control signals into drive signals that can be used for servo valves, ensuring precise actuator action.
quick response
Optimized circuit design to achieve high-speed signal amplification and valve drive response, meeting dynamic control requirements.
high reliability
High quality electronic components and robust design ensure long-term stable operation in industrial environments.
Strong compatibility
Can be used in conjunction with MOOG series servo valves, including proportional valves and servo valves, to achieve overall hydraulic system control.
Easy debugging
Support external parameter adjustment and electrical interface debugging, facilitating system integration and performance optimization.
MOOG 0062-191C 伺服放大器 產品展示
