TRICONEX 3625數字 I/O 模塊PDF資料
1.產 品 資 料 介 紹：
TRICONEX 3625 數字 I/O 模塊 產品特點：
產品概述：
TRICONEX 3625 是 Tricon 安全控制系統（Tricon Safety System）中的數字輸入/輸出模塊，用于采集現場數字信號及執行開關控制命令。該模塊在安全關鍵應用中表現出極高的可靠性與容錯性，是工業安全儀表系統（SIS）的核心部件之一。模塊功能：
集成數字量輸入與輸出通道，能夠?qū)崿F(xiàn)設備狀態檢測、開關量控制、報警輸出等功能，支持多種信號類型。三重冗余架構 (TMR)：
采用 Tricon 典型的 Triple Modular Redundant（三模冗余） 結構設計，三個獨立的通道同時運行，通過投票機制確保任意單點故障不會影響系統整體運行安全。高可靠性與安全等級：
模塊符合 IEC 61508 SIL3 安全完整性等級標準，適用于關鍵過程控制和安全防護系統。通道特性：
提供多路獨立數字輸入/輸出點位（具體點數根據配置而定）
每通道具備獨立隔離設計，防止信號干擾與串?dāng)_
輸入支持干接點與有源信號采集，輸出支持繼電器或晶體管驅動
自診斷功能：
內置全面的自檢和故障檢測機制，可實時監測通道狀態、信號完整性及通信健康狀況，保證系統的安全運行。通訊與數據處理：
與 Tricon 主處理器（Main Processor Module）通過系統總線高速通信，實現信號同步與邏輯控制。可維護性強：
模塊支持帶電熱插拔，更換方便，無需停機即可維護，極大減少系統停機時間。環境適應性：
設計符合工業級標準，具備防震、防塵、防電磁干擾能力，可在惡劣工況下穩定運行。應用領域：
石油天然氣安全控制系統
煉化裝置緊急停車系統 (ESD)
電廠鍋爐與汽輪機保護系統
化工過程安全儀表系統 (SIS)
海上平臺及關鍵過程控制系統
TRICONEX 3625數字 I/O 模塊 英文介紹
TRICONEX 3625 Digital I/O Module Product Features:
Product Overview:
TRICONEX 3625 is a digital input/output module in the Tricon Safety System, used to collect on-site digital signals and execute switch control commands. This module exhibits extremely high reliability and fault tolerance in safety critical applications and is one of the core components of industrial safety instrumented systems (SIS).
Module function:
Integrated digital input and output channels enable device status detection, switch control, alarm output, and support for multiple signal types.
Triple Redundancy Architecture (TMR):
The typical Triple Modular Redundant (the third mock examination Redundant) structure design of Tricon is adopted. Three independent channels operate simultaneously, and the voting mechanism ensures that any single point of failure will not affect the overall operation safety of the system.
High reliability and safety level:
The module complies with the IEC 61508 SIL3 safety integrity level standard and is suitable for critical process control and safety protection systems.
Channel characteristics:
Provide multiple independent digital input/output points (the specific number of points depends on the configuration)
Each channel has an independent isolation design to prevent signal interference and crosstalk
Input supports dry contact and active signal acquisition, output supports relay or transistor drive
Self diagnostic function:
Built in comprehensive self checking and fault detection mechanisms can monitor channel status, signal integrity, and communication health in real-time, ensuring the safe operation of the system.
Communication and Data Processing:
Through high-speed communication with the Tricon Main Processor Module via the system bus, signal synchronization and logic control are achieved.
Strong maintainability:
The module supports hot swapping, making it easy to replace and maintain without shutting down, greatly reducing system downtime.
Environmental adaptability:
Designed to meet industrial standards, it has the ability to withstand shock, dust, and electromagnetic interference, and can operate stably under harsh working conditions.
Application fields:
Oil and gas safety control system
Emergency Shutdown System (ESD) for Refining Equipment
Power plant boiler and turbine protection system
Chemical Process Safety Instrumented System (SIS)
Offshore platform and critical process control system
TRICONEX 3625數字 I/O 模塊 產品展示
