TRICONEX 3503E直流數字輸入模塊 PDF資料
1.產 品 資 料 介 紹：
TRICONEX 3503E 直流數字輸入模塊 產品特點
產品概述：
TRICONEX 3503E 是 Tricon 安全控制系統（Tricon Safety System）中的數字輸入模塊，用于采集現場直流信號并將其傳輸至主處理器模塊，實現安全邏輯控制和過程監控。輸入類型：
支持直流數字輸入信號，通常為 24?V DC。
可采集開關量狀態、接點閉合或斷開信號。
多通道設計：
提供多路獨立輸入通道（典型為 16 或 32 通道，具體型號請參考技術數據表）。
每個通道獨立隔離，防止通道間干擾，提高信號采集可靠性。
三模冗余 (TMR) 架構：
模塊設計符合 Triconex TMR 標準，通過投票機制實現系統容錯。
即使單通道或單模塊出現故障，系統仍能保持正常運行，提高整體安全性。
診斷與自檢功能：
內置通道狀態監測與模塊健康檢查。
異常或故障時自動隔離故障通道并向主處理器報警。
模塊化安裝：
可插入 Triconex 系統機架，與主處理器模塊、輸出模塊及分析模塊無縫協作。
支持熱插拔維護，減少系統停機時間。
工業環境適應性：
具備抗電磁干擾、防震動、防塵、防潮濕能力，可在復雜工業環境下穩定運行。
安全等級與應用：
符合 IEC 61508 SIL3 安全完整性標準，適用于緊急停機 (ESD) 系統、過程聯鎖及關鍵設備保護。
廣泛應用于石油化工、天然氣平臺、煉油廠、電廠及海上平臺等安全關鍵工業系統。
TRICONEX 3503E直流數字輸入模塊 英文介紹
TRICONEX 3503E DC Digital Input Module Product Features
Product Overview:
TRICONEX 3503E is a digital input module in the Tricon Safety System, used to collect on-site DC signals and transmit them to the main processor module for safety logic control and process monitoring.
Input type:
Supports DC digital input signals, typically 24V DC.
Can collect switch status, contact closure or disconnection signals.
Multi channel design:
Provide multiple independent input channels (typically 16 or 32 channels, please refer to the technical data sheet for specific models).
Each channel is independently isolated to prevent interference between channels and improve signal acquisition reliability.
The third mock examination Redundancy (TMR) architecture:
The module design complies with the Triconex TMR standard and achieves system fault tolerance through a voting mechanism.
Even if a single channel or module fails, the system can still maintain normal operation, improving overall safety.
Diagnostic and self checking functions:
Built in channel status monitoring and module health check.
Automatically isolate the faulty channel and alert the main processor in case of abnormality or malfunction.
Modular installation:
Can be inserted into the Triconex system rack, seamlessly collaborating with the main processor module, output module, and analysis module.
Support hot swappable maintenance to reduce system downtime.
Industrial environment adaptability:
It has the ability to resist electromagnetic interference, vibration, dust, and moisture, and can operate stably in complex industrial environments.
Security level and application:
Compliant with IEC 61508 SIL3 safety integrity standard, suitable for emergency shutdown (ESD) systems, process interlocks, and critical equipment protection.
Widely used in safety critical industrial systems such as petrochemicals, natural gas platforms, refineries, power plants, and offshore platforms.
TRICONEX 3503E直流數字輸入模塊 產品展示
