MVME712/M工控模塊系統備件
但是，請注意，按Esc鍵與單擊“取消”按鈕相同。15.1.7上傳參數時如果您正在導出驅動器的參數，上傳這些參數需要一段時間。光標變?yōu)樯陈?，狀態欄通知您導出。15.1.8驅動器導出參數示例在本示例中，導出時使用文本格式。請注意，當導出所有驅動器或打開的參數文件時，導出文件的內容類似。文件標識標簽和注釋是前兩行。驅動器或參數文件的名稱在其上下各有一個空行。如果導出了所有驅動器，它們將按順序顯示在文件中。參數、信號和故障4-136 DriveWindow 2以下顯示文件導入Word并轉換為表格時的文件開頭。邊框也被添加了。15.1.9導出參數差異示例以下顯示了文件導入Word并轉換為表格時的文件開頭。邊框也被添加了。另請參閱：什么是參數和信號如何保存參數如何打印參數什么是參數文件打開參數文件關閉參數文件如何比較導出文件的參數處理參數、信號和故障DriveWindow 2 4-137 16。如何進行系統軟件版本升級版本升級是將新版本的系統軟件安裝到已調試的驅動器中，以避免重新輸入?yún)?shù)值。注意，DriveWindow無法處理本地DriveDA OPC服務器驅動器（AC880系列）的系統軟件。因此，您不能使用DriveWindow升級ACS880系列驅動器的系統軟件。只有在新系統軟件版本與舊系統軟件版本兼容的情況下，才能進行版本升級，即調試期間需要設置的參數具有相同的組和索引值，并且其值具有相同的縮放比例。如果僅存在細微差異（例如，新參數），仍可進行升級，但升級后需要手動調整參數。16.1.1準備雖然并非絕對必要，但我們建議您對所有要升級的驅動器進行完整備份，除非您已經有可用的驅動器。如果升級過程中出現問題，可能需要備份。但是，需要保存所有要升級的驅動器的參數。根據DDCS網絡配置和用于下載新系統軟件的工具，您可能需要重新連接DDCS網絡。?如果下載工具不是DriveWindow，并且它僅支持點對點連接，則必須將要升級的驅動器直接連接到您的電腦。?如果您要在下載時使用DriveWindow，則可能是您的DDCS網絡已根據建議進行了配置，并且在節點地址1處有一個驅動器（節點地址1為備用部件預留）。如果要升級除節點地址為1的驅動器之外的驅動器，請斷開節點地址為一的驅動器與網絡的連接，或?qū)⑵鋽嚯姡僭O(shè)它位于分支單元后面）。
Note, however, that pressing the Esc key is same than clicking the Cancel button. 15.1.7 While the parameters are uploaded If you are exporting parameters of a drive, uploading of them takes for a while. The cursor turns to hour-glass and the status bar informs you about exporting. 15.1.8 Example of exported parameters of a drive In this example the text format is used in exporting. Note that content of the exported file is similar, when all of the drives or an open parameter file is exported. The file identification tag and the comment are the first two lines. The name of the drive or the parameter file has an empty line above and below it. If all drives are exported, they appear in the file sequentially. Parameters, Signals, and Faults 4-136 DriveWindow 2 The following shows the beginning of the file, when it has been imported to Word, and converted to a table. Borders have been added, too. 15.1.9 Example of exported parameter differences The following shows the beginning of the file, when it has been imported to Word, and converted to a table. Borders have been added, too. See Also: What are Parameters and Signals How to Save Parameters How to Print Parameters What is Parameter File Opening a Parameter File Closing a Parameter File How to Compare Parameters Handling of Exported Files Parameters, Signals, and Faults DriveWindow 2 4-137 16. How to Do System Software Version Upgrade Version upgrade is installing new version of system software into an already commissioned drive so that re-entering of parameter values is avoided. Note that DriveWindow is not able to handle system software of native DriveDA OPC server drives (AC880 family). So, you cannot use DriveWindow to upgrade system software of ACS880 family of drives. Version upgrade is possible only, if the new system software version is compatible with the old one, i.e., the parameters required to be set during commissioning have the same group and index values, and their values have the same scaling. If there are just minor differences (new parameters, for example), upgrading can still be done, but manual adjustment of parameters are required after upgrading. 16.1.1 Preparing Although not absolutely necessary, we recommend that you take full backup of all drives to be upgraded, unless you have them already available. The backup may be required, if something goes wrong during the upgrade.However, saving of parameters of all drives to be upgraded, is required. Depending on the DDCS network configuration and the tool you are going to use to download the new system software, you may be need to make reconnections in the DDCS network. ? If the download tool is not DriveWindow and it supports only point-to-point connection, you have to connect the drive to be upgraded directly to you PC. ? If you are going to use DriveWindow in downloading, it may be that your DDCS network has been configured against recommendations, and has a drive at node address one (node address one is reserved for spare parts). If you are going to upgrade a drive other than the one with node address one, either disconnect the drive with node address one from the network, or power it down (assuming it is behind a branching unit).
