OKUMA E4809-770-065-A伺服驅動放大器
DNP端口：選擇用于DNP協議的適當PQM端口。只有在PQM中安裝了T1或T20選項時，COM2選項才可用。每個端口的配置如圖4–4：設置點第1頁–PQM設置/通信端口第4–7頁所示。?DNP從屬地址：為此特定PQM輸入從0到255的唯一地址。所選地址應用于當前分配使用DNP協議通信的PQM端口。盡管地址不必是連續的，但菊花鏈連接在一起的兩個PQM都不能具有相同的地址，否則會有沖突導致錯誤。通常，添加到鏈接的每個PQM將使用下一個更高的地址。?DNP周轉時間：如果使用RS232端口，則將周轉時間設置為零。周轉時間在使用無RTS或DTR開關的RS485轉換器的應用中非常有用。延遲的典型值為30ms，以允許變送器在RS485轉換器中下降。
DNP PORT: Select the appropriate PQM port to be used for DNP protocol. The COM2 selection is only available if T1 or T20 option is installed in the PQM. Each port is configured as shown in FIGURE 4–4: Setpoints Page 1 – PQM Setup / Communication Ports on page 4–7. ? DNP SLAVE ADDRESS: Enter a unique address from 0 to 255 for this particular PQM. The address selected is applied to the PQM port currently assigned to communicate using the DNP protocol. Although addresses do not have to be sequential, no two PQMs that are daisy chained together can have the same address or there will be conflicts resulting in errors. Generally each PQM added to the link will use the next higher address. ? DNP TURNAROUND TIME: Set the turnaround time to zero if the RS232 port is being used. The turnaround time is useful in applications where the RS485 converter without RTS or DTR switching is being employed. A typical value for the delay is 30 ms to allow the transmitter to drop in the RS485 convertor.
