When a board is stored, if the battery is present, it should be
disconnected to prolong battery life. This is especially important at
high ambient temperatures. MVME177 boards with battery backup
are shipped with the batteries disconnected.
The power leads from the battery are exposed on the solder side of
the board, therefore the board should not be placed on a conductive
surface or stored in a conductive bag unless the battery is removed.
Note Lithium batteries incorporate inflammable materials
such as lithium and organic solvents. If lithium
batteries are mistreated or handled incorrectly, they
may burst open and ignite, possibly resulting in injury
and/or fire. When dealing with lithium batteries,
carefully follow the precautions listed below in order to
prevent accidents:To remove the battery from the module, carefully pull the battery
from the socket.
Onboard DRAM
The MVME177 onboard DRAM is located on a mezzanine board.
The mezzanine boards use error checking and correction (ECC)
protection to correct single-bit errors and detect double-bit errors.
Interrupts or bus exception can be enabled when a bit error is
detected. The interrupt output from the memory mezzanine is
connected to the VMEchip2 PEIRQ* interrupt input.Two mezzanine boards may be stacked to provide 256MB of
onboard RAM. The main board and a single mezzanine board
together take one slot. The stacked configuration requires two
VMEboard slots. The DRAM is four-way interleaved to efficiently
support cache burst cycles.
The DRAM map decoder can be programmed to accommodate
different base address(es) and sizes of mezzanine boards. The
onboard DRAM is disabled by a local bus reset and must be
programmed before the DRAM can be accessed. Refer to the
MCECC in the Single Board Computers Programmer's Reference Guide
for detailed programming information. Most DRAM devices
require some number of access cycles before the DRAMs are fully
operational. Normally this requirement is met by the onboard
refresh circuitry and normal DRAM initialization. However,
software should insure a minimum of 10 initialization cycles are
performed to each bank of RAM.
